6300-63000KVA 110KV High-capacity Three-phase Oil-immersed Power Transformer

Henan GNEE Electric Co., Ltd. is one of the leading manufacturers and suppliers of 6300-63000kva 110kv high-capacity three-phase oil-immersed power transformer in China, also supports customized service with low price. Welcome to buy discount 6300-63000kva 110kv high-capacity three-phase oil-immersed power transformer for sale here from our factory. If you have any enquiry about pricelist, please feel free to email us.

110KV Three-Phase Oil-Immersed Power Transformer is manufactured in compliance with the International Electrotechnical Commission standard IEC 60076 and the National Standard GB 1094 of the People's Republic of China. The series features excellent impact resistance, high mechanical strength, strong short-circuit withstand capability, low partial discharge, low noise, low loss, excellent sealing performance, and minimal maintenance requirements. It is suitable for use as a main transformer in power plants, substations, and urban/rural power grid transmission and distribution systems. The product has passed two authoritative appraisals and was certified as qualified in the 2002 National Supervision and Sampling Inspection.

Contact now

Core
The three-phase oil-immersed power transformer adopts a high-quality cold-rolled grain-oriented silicon steel core. It features a fully inclined hole-free structure and uses low-carbon steel plates as tension plates to rigidly connect the upper and lower clamps with the core, effectively reducing no-load losses and lowering noise levels.

Windings
Depending on the transformer capacity, windings employ cylindrical, spiral, or continuous structures. For windings rated at 110kV or higher, interleaved or internal shielding configurations are utilized to optimize impulse voltage distribution. Transposed or composite conductors minimize additional winding losses. Computer-aided simulations ensure precise calculations of electric fields and impulse characteristics, guaranteeing superior electrical performance and mechanical strength. Robust manufacturing processes further enhance operational reliability.

Compression Structure
The transformer body utilizes an integral circular insulating pressure plate. A fully integrated winding assembly process significantly improves product reliability.

Tank Design
The flat-top bell-type tank incorporates folded-plate reinforcing ribs on the walls to enhance mechanical strength. Large transformers are equipped with magnetic shielding on the inner tank walls to reduce stray losses.

Safety Features

Positioning devices prevent core displacement during transportation.

A sealed conservator isolates transformer oil from atmospheric moisture, preventing degradation and aging.

A pointer-type oil level indicator is installed at the terminal.

Pressure relief valves are mounted on the tank top, calibrated to the oil weight, ensuring safe operation.
