23QG100 GO Silicon Steel
Description
Technical Parameters
Henan GNEE Electric Co., Ltd. is one of the leading manufacturers and suppliers of 23qg100 go silicon steel in China, also supports customized service with low price. Welcome to buy discount 23qg100 go silicon steel for sale here from our factory. If you have any enquiry about pricelist, please feel free to email us.
Oriented silicon steel Description
Oriented silicon steel, also known as cold-rolled oriented silicon steel, contains 2.9% - 3.5% silicon. Its crystal grains are arranged in a specific orientation, which gives it unique magnetic properties. This type of silicon steel has extremely low core loss and high magnetic permeability along the rolling direction. It's mainly used in manufacturing transformer cores, significantly enhancing transformer efficiency and reducing energy consumption. In the power industry, its application helps save a large amount of electricity. Also, crgo silicon steel plays an important role in new energy and electronic device manufacturing fields.
cold-rolled oriented silicon steel Video
23QG100 GO silicon steel And other grade silicon steel parameter
| Thickness (mm) |
Trademark | Theoretical density (Kg/dm2) | Iron loss(W/Kg ) | Magnetic induction (T) |
| 0.23 | 23Q110 | 7.65 | 1.10 | 1.81 |
| 0.27 | 27Q120 | 1.20 | 1.82 | |
| 27Q130 | 1.30 | 1.81 | ||
| 0.30 | 30Q120 | 1.30 | 1.82 | |
| 0.23 | 23QG090 | 0.90 | 1.88 | |
| 23QG095 | 0.95 | |||
| 23QG100 | 1.00 | |||
| 0.27 | 27QG095 | 0.95 | 1.89 | |
| 27QG100 | 1.00 | |||
| 27QG120 | 1.20 | |||
| 0.30 | 30QG105 | 1.05 | ||
| 30QG120 | 1.20 |
Manufacturing Process and Performance Control of High Permeability Grain-Oriented Silicon Steel (HiB)
The production of GO silicon steel is regarded as the "crown jewel" of metallurgical industry, involving 18 critical processes including steelmaking, hot rolling, normalization, and cold rolling. In the decarbonization annealing stage, the material must be treated for 5 minutes in an 800°C hydrogen-nitrogen mixed atmosphere to maintain carbon content below 30ppm. For more sophisticated HiB steel (high permeability grain-oriented silicon steel), additional laser scribing is required to create micron-scale grooves on the surface, reducing magnetic domain width to under 2mm.
The shape control in cold rolling is an art form - a six-high rolling mill must reduce 3mm-thick hot-rolled plates to 0.3mm with thickness deviation within ±3μm. The continuous decarbonization annealing line utilizing electromagnetic induction heating can uniformly heat steel strips to 830°C at 20m/min, forming perfect secondary recrystallization structures. The precise control of these processes directly determines the final magnetic performance grade of crgo silicon steel.
about us
18+ years of silicon steel sheet manufacturing experience
Gnee Steel (tianjin) Co., Ltd
more than 160 cooperative countries, and has established long-term cooperation with more than 8,000 customers
Professional, efficient and good service
Do things sincerely, connect the world
